Riland Plasma Machine CUT-40CT 220V C/W 5m Torch PT-31 & 3m Earth Clamp | Model : W-CUT40CT-R

Features :

• Use 100 KHz inverter MOSFET technology.
• Delicate angle bead, more protection and more
  beautiful shape.
• Adopt new techniques that maximizing thermal
  dissipation with 4 separated heat sinks.
• Greatly improved the welding performance and
  stability; easy striking under low voltage.
• Professional in cutting thin steel to meet general
  demands.
• Current and gas post time adjustable, fully cooled
  electrode and nozzle.
• Recommended for 12mm thickness steel, limited for
  16mm thickness steel.
• Intelligent protection: overvoltage, overloading
  and overheating.
• Energyefficient: power factor more than 0.7,
  efficiency more than 85%.

Specifications :

• Model : CUT40CT
• Input Voltage : AC220V 15%
• Frequency : 50 Hz
• Rate Input Current : 30 A
• No- Load Voltage : 275 V
• Current Range : 15-40 A
• Rate Output Voltage : 96 V
• Duty Cycle : 30 %
• Efficiency : 80 %
• Power Factor : 0.78
• Arcing Way : Cotact
• Pressure of air compressor : 4-5 kgf/cm2
• Limited Cutting Thickness : 16 mm
• Recommended Cutting Thickness : 1 – 10 mm
• Weight : 7.3 kg
• Dimensions : with angle 402 (L) x 160 (W) x 300 (H) mm
